The Link Selection screen (#85) in Figure 3-2 “Link Selection Screen” is displayed when you press the [Go To LINK]
function key at the Unguided Configuration screen (#80). It is also
displayed when you type the path name: @LINK in the command window of any screen and press the [Enter]
key. | | | |  | NOTE: Fields described as "HP modifiable"
should be changed only upon the recommendation of your HP representative.
| | | | |
Figure 3-2 Link Selection Screen
![[Link Selection Screen]](img/gfx8.gif)
| | | | | NOTE: NS/SNA is no longer offered as a product and has been
removed from the Corporate Price List. The product is obsolete with
no plans for support. | | | | |
Use the fields and the function keys of the select screen
to perform the desired action as follows: To define a new link configuration,
specify the link name and the type; then press the [Add]
function key. The path for the selected link name is added to the
configuration file and the data screen for the type specified is
displayed. To modify an existing link configuration, specify
the linkname; then press the [Modify]
function key. The data screen that contains information for the
specified link name is displayed. To change the name of an existing link configuration,
specify the link name and a new name; then press the [Rename]
function key. The previously configured link name is replaced and
the screen displays the new name in the display fields labeled Configured
Link Interfaces. To delete an existing link configuration, specify
the link name, then press the [Delete] function
key. Press the [Delete] function key again to confirm
the deletion. The previously configured link name and associated
data is deleted and is no longer displayed in the display fields
labeled Configured Link Interfaces.
Fields- Link name
Enter the link name for either a LAN, LAP-B, X.25,
NS/SNA, Token Ring, FDDI, 100VG-AnyLAN, or 100Base-T. The link name can contain as many as eight alphanumeric characters,
and the first character must be alphabetic. This name must match
the link name configured in the corresponding NETXPORT.NI.NIname.LINK screen. - Types
(Required only when adding a link.)
Enter the type shown on the screen that corresponds to your link. Choose LAN
if you are using a ThinLAN, ThickLAN, or Ethertwist link. Refer
to LAN Link Configuration. Choose LAPB if
you are using a point-to-point (router) Link. Refer to Link Configuration:
LAP-B Link Data. Choose X.25 if
you are using an X.25 link. Refer to X.25 Link Configuration. Choose TOKEN if
you are using a token ring link. Refer to Token Ring Link Configuration. Choose FDDI if
you are using an FDDI link. Refer to FDDI Link Configuration. Choose 100VG-AnyLAN
if you are using an 100VG-AnyLAN link. Refer to 100VG-AnyLAN Link
Configuration. Choose 100Base-T
if you are using an 100Base-T link. Refer to 100Base-T Link Configuration.
NS/SNA is no longer offered as a product. - New name
(Required only when renaming a link.)
Enter a new link name. The new name can contain as many as eight
alphanumeric characters, and the first character must be alphabetic.
The link name must match the link name configured in the corresponding
NETXPORT.NI.NIname.LINK screen.
|
