Information Access Server: Learning the Administrator Utility

A : Using the Print Function Label

Whenever you List or Show a definition, the  Print  f1 function label
lets you print that listing or individual definition.  To learn about
this function, print a list of all defined databases.




                                  Go to screen  LIMD

---------------------------------------------------------------------------------------------
|                                             |                                             |
|                 What You Do                 |                What Happens                 |
|                                             |                                             |
---------------------------------------------------------------------------------------------
|                                             |                                             |
| A-1.  Go directly to the List IMAGE         | Configured databases are listed             |
| Databases (LIMD) screen.                    | alphabetically.                             |
|                                             |                                             |
---------------------------------------------------------------------------------------------
|                                             |                                             |
| You can now send the displayed information  |                                             |
| to the system printer.                      |                                             |
|                                             |                                             |
| A-2.  Choose:                               | A printout of the List IMAGE Databases      |
|                                             | screen is generated.  It will be printed    |
|        Print  f1                            | when you leave the Administrator Utility.   |
|                                             |                                             |
|                                             |                                             |
---------------------------------------------------------------------------------------------
|                                             |                                             |
| A-3.  Choose:                               | The IMAGE Database Menu appears.            |
|                                             |                                             |
|        Done  f8                             | From here, you can go on to the next task.  |
|                                             |                                             |
|                                             |                                             |
---------------------------------------------------------------------------------------------
