Function Keys Screen This screen allows you to name a function key set and define the actions performed by the keys. Screen ImageField Descriptions Function Keys Enter the name of the function key set (up to 16 characters). If you haven't previously defined the name, HP ALLBASE/4GL assumes you're defining a new function key set and displays the default function key set. (Refer to Additional Information.) Action Enter the code of the action to be carried out by HP ALLBASE/4GL when the user presses the function key. The available action codes and their meanings are: Code Action Type B- Background process D- Data screen or menu F- Function logic block H- Help screen I- Internal action K- Call another function key set P- Process logic block R- Report X- External program blank No action performed To specify an action, enter the action code followed by a hyphen and the action name. For example, D-emp_details displays the screen emp_details. Label Text Enter the screen label text for the function key. The label can use two lines of text, each containing up to eight characters. Switch Number Optional. Enter a number from 1 to 8, representing one of the HP ALLBASE/4GL user switches. If you enter a switch number in this field, HP ALLBASE/4GL displays an asterisk in the function key label on the application screen at run-time while the switch is on. If the key label has one line of text, the asterisk is placed in column 8 in the top line of text. If the label has two lines of text, the asterisk is placed in the bottom line of the label. The asterisk is not displayed while the switch is off. Typically you would use this feature to provide the end user with a visual indication of the status of a function. For example, you could use a function associated with the function key to toggle a particular operating mode (such as an add mode, modify mode, or delete mode) on or off. By setting a switch on or off in the function, you can provide the end user with a visual indication of the current operating mode. Function Keys f1 Screen Header Cancels the current screen and displays the screen header screen. f2 Screen Painter Cancels the current screen and runs the screen painter program. f3 Field Details Cancels the current screen and displays the screen fields detail screen. Additional Information Function Key Display Logic. HP ALLBASE/4GL displays function key sets on application screens according to the following rules: * If the current screen has a set of function keys defined for it, these keys are displayed when the screen is executed. * If the current screen has a window displayed on it, and the window has its own set of function keys, the function keys for the window are displayed. If the window does not have its own set of function keys, the function keys for the main screen (if defined) are displayed. * If the current screen does not have a set of function keys defined for it, HP ALLBASE/4GL displays the function key set default_keys from the local application, or if these don't exist, the function key set default_keys from the administrator application. If HP ALLBASE/4GL cannot find a set of function keys defined for a screen or window, it searches for a set of function keys with the same name in the administrator application. If no other keys can be found, HP ALLBASE/4GL displays the default_keys function key set from the administrator application. If HP ALLBASE/4GL cannot read a set of function keys called by a K- action from a function key, it searches for a set of function keys with the same name in the administrator application. If no other keys can be found, HP ALLBASE/4GL displays the default_keys function keys from the administrator application. HP ALLBASE/4GL Internal Routines You can use function keys on application screens to initiate any HP ALLBASE/4GL internal routine. To assign an internal routine to an application screen function key, enter I-followed by the internal routine name in the action field on the function keys definition screen. The internal routines are described in the following paragraphs. I-BACKTAB The I-BACKTAB internal routine moves the screen cursor as if the Shift + Tab keys and then the Return key sequence have been pressed. This provides faster reverse tabbing for end-users when they use one of the function keys to call I-Backtab. I-CLEAR This routine clears all input and display-only fields on the current screen. I-COMMIT The I-COMMIT internal routine terminates all current screen processing. Typically, you provide the user with a Commit Data function key to invoke the I-COMMIT internal routine. The user can press the function key to indicate that data entry on the screen has been completed. By default, HP ALLBASE/4GL assigns this internal routine to function key number 6 in a new set of function keys. On a data screen or window, HP ALLBASE/4GL executes the I-COMMIT internal routine immediately if the current screen field has been processed. If the current field has not been processed, HP ALLBASE/4GL processes this field and then executes the I-COMMIT internal routine. After the I-COMMIT internal routine, HP ALLBASE/4GL resumes running the application in one of three possible ways, depending on how the screen was displayed. * If the screen was displayed by a SCREEN command in a logic block, control returns to the command immediately following the SCREEN command. * If the screen was displayed directly from a menu, control returns to the menu. * If the screen was displayed from a function called from a field on another screen, or a function key on another screen, HP ALLBASE/4GL firstly returns to the function and executes the remaining commands. Control then returns to the logic block or menu that displayed the original screen. On a menu, the I-COMMIT internal routine immediately executes the selected item. I-EXIT The I-EXIT internal routine terminates execution of HP ALLBASE/4GL and returns to the original MPE/iX operating system level. I-HELP The I-HELP internal routine displays the help screen associated with the current message, field, or screen. By default, HP ALLBASE/4GL assigns this action to function key number 7 in a new function key set. I-hpqm_call This routine temporarily suspends execution of HP ALLBASE/4GL and starts HP ALLBASE/QUERY. The normal HP ALLBASE/QUERY welcome screen is bypassed, and the user is automatically connected to the application's HP ALLBASE/SQL database. When the user exits from HP ALLBASE/QUERY, normal HP ALLBASE/4GL processing is resumed. If the current application has an open SQL transaction when the user presses a function key that calls this action, HP ALLBASE/4GL displays a warning message, and allows the user to complete or reverse the transaction before starting HP ALLBASE/QUERY. I-image_dbchg_call This routine suspends HP ALLBASE/4GL processing and invokes the HP TurboIMAGE DBchange/XL program. When the user exits from the HP TurboIMAGE DBchange/XL program, HP ALLBASE/4GL processing resumes at the point where the I-image_dbchg_call routine was called. I-image_dbutl_call This routine suspends HP ALLBASE/4GL processing and invokes the HP TurboIMAGE DBUTIL program. When the user exits from HP TurboIMAGE DBUTIL, HP ALLBASE/4GL processing resumes at the point where the I-image_dbutl_call routine was called. I-image_query_call This routine suspends HP ALLBASE/4GL processing and invokes the HP QUERY/XL program, if it is on your system. When the user exits from HP QUERY/XL, HP ALLBASE/4GL processing resumes at the point where the I-image_query_call routine was called. I-isql_call Suspends HP ALLBASE/4GL processing and invokes the HP ISQL program. When the user exits from HP ISQL, HP ALLBASE/4GL processing resumes at the point where the I-isql_call routine was called. I-logon The I-logon internal routine immediately terminates the current application and displays the HP ALLBASE/4GL sign-on screen. (Note that this routine name is in lowercase letters.) Typically, you would use this internal routine to provide the end-user with a Sign-on Screen function key. I-MAINMENU The I-MAINMENU internal routine displays the application main menu. This is either the initial action specified for the application on the administrator application definition screen (Refer to the HP ALLBASE/4GL Developer Administration Manual), or the first menu displayed by the application if the application's initial action is a process. If no menu has been displayed, the application is terminated. The I-MAINMENU internal routine terminates the current screen and logic block immediately. I-PREVKEYS Replaces the function keys on the application screen with the previous set of function keys. I-PREVMENU If HP ALLBASE/4GL is displaying a menu, the internal routine I-PREVMENU immediately returns control to the previous menu. If HP ALLBASE/4GL is displaying a data screen, but the user has not entered any data on the screen, the I-PREVMENU internal routine returns control to the last menu displayed by the system. The I-PREVMENU routine immediately terminates any current process, function or decision table. If the user has started entering data on the data screen, the I-PREVMENU internal routine initially displays a message informing the user that the screen has not been committed. A second I-PREVMENU internal routine returns control to the last menu displayed by the system without committing any data entered so far. Any current module, process, function or decision table is terminated immediately. By default, HP ALLBASE/4GL assigns the I-PREVMENU internal routine to function key number 8 in a new function key set. I-PRINT Prints the screen and the contents of all fields. The destination printer is determined by the HP-UX variable HP4SCREEN_PRINT. If HP4SCREEN_PRINT is undefined, HP ALLBASE/4GL writes the screen image to the formal file designator HP4REP. If HP4SCREEN_PRINT exists, but is null (that is, its value is the empty string "") HP ALLBASE/4GL attempts to print the screen image on a slave printer attached to the user's terminal. If HP4SCREEN_PRINT exists and contains a non-null value, screen printing is inhibited. I-REFRESH Repaints the screen and the contents of all fields. I-RESET Performs a terminal soft reset sequence. I-SHELL Suspends HP ALLBASE/4GL processing and invokes the MPE/iX command interpreter. When the user exits from the MPE/iX command interpreter, HP ALLBASE/4GL processing resumes at the point where the SHELL command was issued. Users can execute a specific a command interpreter by setting the SHELL variable. MPE/iX executes the command interpreter defined by this variable. If the SHELL variable is not defined, this internal routine calls the command interpreter program CI.PUB.SYS by default. The system administrator can change this default. I-SLAVE_PRINT Prints an image of the current screen on a slave printer attached to the user's terminal. If no slave printer is attached to the terminal, this command times out after about five seconds and HP ALLBASE/4GL issues a message asking the user to either retry or abort the command. I-TAB The I-TAB internal routine moves the screen cursor as if the Tab key has been pressed. This internal routine is provided to accompany the I-BACKTAB internal routine. I-TRACEMODE Toggles the HP ALLBASE/4GL trace mode on or off. When trace is active, HP ALLBASE/4GL displays the current logic block and step for about three seconds, and then proceeds to the next step. Refer to chapter 14 for more information on trace mode. I-TRAIN Toggles the HP ALLBASE/4GL training mode on or off. If the system administrator has set the application user into training mode, this internal action does not disable the mode. In this case, the training mode can only be disabled by the system administrator. Default Function Key Definitions When you're defining a new function key set, HP ALLBASE/4GL supplies a number of default function key definitions automatically. You can set up your own default function key set in the application you're developing by a defining a function key set called default_keys. Each time you create a new set of function keys, HP ALLBASE/4GL will display this set of default key actions and labels. You can type over the defaults if they don't suit the screen you are working on. Note that if you define a set of default keys in your application, these keys will be displayed on an application screen unless you specify a different set of function keys on the screen header for the application screen. If you don't define a function key set called default_keys in your application, HP ALLBASE/4GL displays the function key set default_keys from the administrator application as the default each time you create a new function key set in your application. If you are in test mode, you may see a different set of default keys than you see when accessing other developer screens. The following tables list the default function keys for developer screens and test mode. The first table lists the administrator application default function keys. These keys are available in both developer screens and in test mode. Key Action Key Label Text 5 K-global_keys_1 System Keys 6 I-COMMIT Commit Data 7 K-HELP Help 8 I-PREVMENU Previous Menu The function key set global_keys_1 from the administrator application supplies the definitions for the System Keys function keys to function key number 5. These keys are available in both developer screens and in test mode. The actions and key labels for these keys are as follows: Key Action Key Label Text 1 I-MAINMENU Main Menu 2 K- print_scrn_keys Screen Printing 3 I-CLEAR Clear Screen 4 I-REFRESH Refresh Screen 5 I-PREVKEYS Previous Keys 6 K- global_keys_2 More Keys 7 I-HELP Help 8 I-PREVMENU Previous Menu The K- global_keys_2 action assigns the key set global_keys_2 from the administrator application to the More Keys function key in the System Keys function key set. These keys are available only on the developer screen; they are not available in test mode. The actions and key labels for this function key set are: Key Action Key Label Text 2 I-SHELL Op. System 3 I-isql_call ISQL 4 I-hpqm_call ALLBASE QUERY 5 I-PREVKEYS Previous Keys 6 K-global_keys_3 More Keys 7 I-HELP Help 8 I-EXIT Exit The K- global_keys_2 action in test mode assigns the following key set global_keys_2 to the More Keys function key in the System Keys function key set. These keys are available only in test mode. The actions and key labels for this function key set are: Key Action Key Label Text 2 I-SHELL Op. System 3 I-TRAIN Training Mode 4 I-TRACEMODE Trace Mode 5 I-PREVKEYS Previous Keys 7 I-HELP Help 8 I-EXIT Exit The K- global_keys_3 action assigns the key set global_keys_3 from the administrator application to the More Keys function key in the More Keys function key set. These keys are available only in the developer screens. The actions and key labels for this function key set are: Key Action Key Label Text 1 I-image_dbutl_call T'IMAGE DBUTIL 2 I-image_query_call T'IMAGE QUERY 3 I-image_dbchg_call T'IMAGE DBCHANGE 5 I-PREVKEYS Previous Keys 7 I-HELP Help 8 I-EXIT Exit The K-print_scrn_keys action in the global_keys_1 function key set assigns the function key set print_scrn_keys from the administrator application to function key number 2 in the System Keys function keys. These keys are available in the developer screens and in test mode. The actions and key labels for the print_scrn_keys function key set are: Key Action Key Label Text 3 I-PRINT To System 4 I-SLAVE_PRINT To Local 5 I-PREVKEYS Previous Keys In test mode you can override the four system function key sets, global_keys_1, global_keys_2, global_keys_3, and print_scrn_keys, for a particular application by defining function key sets with the same names in your application.
![[]](../../pic3k/M012310/FFN433c50.gif)
