H : Configuring Access Groups and Users Now you're ready to configure two access groups and two users--MANAGERS with user SALESMGR, and TUTORIAL with user TUTORIAL. Figure 2-3 shows Worksheet 2 with the access group and user information filled in. The access group defines the capabilities its users can exercise. The user definition is your chance to name users, give them passwords (if desired), and define their access to system resources such as number of saved tables, disc space, and MPE priority in the server process. You can also define them as secondary DBAs. Here's what the system will look like when you add these access groups and users:Figure 2-10. Access Groups MANAGERS and TUTORIAL, Users SALESMGR and TUTORIAL Added ___________________________________________________________ | | | References in this Learning manual: | | Lesson 1:D, How the Data Dictionary is Configured| | Figure 2-3, Worksheet 2 Completed | | | | References in Information Access Server: Database | | Administration: | | Chapter 6, Configuring Access Groups: | | Access Group Menu | | Adding an Access Group Definition | | Chapter 7, Configuring Users: | | User Menu | | Adding a User Definition | ___________________________________________________________ Adding an Access GroupGo to screen AG --------------------------------------------------------------------------------------------- | | | | What You Do | What Happens | | | | --------------------------------------------------------------------------------------------- | | | | First, add an access group. Go directly to | | | the Add Access Group (AG) screen. | | | | | | H-1. Type AG in the Go to screen field and | The Add Access Group screen appears. | | press Enter. | | | | | | H-2. Type MANAGERS in the Access Group | The Access Group field clears. You have | | field and leave the default of 1 in the | successfully configured the access group | | Capability field, then press Enter. | MANAGERS with normal capability. | | | | | | This means that users assigned to this | | | access group will be able to access those | | | tables allowed by the configured table | | | security (covered in Lesson 2:I). However, | | | they will not be able to add database | | | definitions or add and delete table | | | definitions. | | | | --------------------------------------------------------------------------------------------- | | | | If you wanted to configure more access | | | groups you could do so now, but instead, | | | configure a user for this access group. | | | | | | H-3. Choose: | The Access Group Menu appears. | | | | | Done f8 | | | | | | | | --------------------------------------------------------------------------------------------- Adding a UserGo to screen AU --------------------------------------------------------------------------------------------- | | | | What You Do | What Happens | | | | --------------------------------------------------------------------------------------------- | | | | Now assign user SALESMGR to access group | | | MANAGERS. | | | | | | H-4. Type AU in the Go to screen field, | You have moved directly to the Add User | | then press Enter. | (AU) screen. | | | | | H-5. Type SALESMGR in the User field, tab | The definition is accepted and the screen | | past the User Password field, type MANAGERS | clears. | | in the Access Group field, and ignore the | | | remaining fields. Then press Enter. | You've configured SALESMGR as the sole | | | member of the access group MANAGERS. The | | | user SALESMGR will not need a password and | | | can use an unlimited number of saved tables | | | and disc space with the default MPE | | | priority (the CS queue). Also, the user | | | SALESMGR does not have DBA capability. | | | | --------------------------------------------------------------------------------------------- | | | | H-6. Choose: | The User Menu returns. | | | | | Done f8 | | | | | | | | --------------------------------------------------------------------------------------------- Adding Another Access Group and User --------------------------------------------------------------------------------------------- | | | | What You Do | What Happens | | | | --------------------------------------------------------------------------------------------- | | | | Now that you know how to define an access | | | group and assign users to it, configure a | | | new access group and user on your own. | | | | | | H-7. Using the information in filled-in | | | Worksheet 2 (Figure 2-3), repeat Steps H-1 | | | through H-6 for access group TUTORIAL and | | | user TUTORIAL. | | | | | | Remember to include the password USER (all | | | uppercase), which you'll find listed on the | | | worksheet for the user TUTORIAL. | | | | | | | You have successfully configured another | | | access group and assigned a user to it. | | | | --------------------------------------------------------------------------------------------- Summary Thus far in Lesson 2, you have learned how to: * Define the identity and location of an IMAGE database. * Derive IMAGE and view tables from it. * Identify particular PC users who can use Access Server to retrieve information.
