Neighbor Gateways

The Neighbor Gateways screen (#152) in figure 6-11 is displayed when you
press the [Go To INTERNET] function key at the Point-to-Point Network
Interface Config screen (figure 6-3).  It is also displayed when you type
the path name:

@NETXPORT.NI.NIname.INTERNET

in the Command window of any screen and press the [Enter] key, where the
NIname is a configured point-to-point NI.


          Figure 6-11.  Neighbor Gateways

Use this screen, and the screens that follow it, to identify the gateways
on this network.  Use the fields and the function keys of this select
screen to perform the desired action as follows:

   *   To identify a new gateway, specify the gateway name; then press
       the [Add] function key.  The path for the selected gateway name is
       added to the configuration file, and the data screen on the path
       is displayed.Up to 164 gateways are supported per link.

   *   To modify an existing gateway identification, specify the gateway
       name, then press the [Modify] function key.  The data screen on
       the path for the specified gateway is displayed.

   *   To change the gateway name of an existing gateway identification,
       specify the gateway name and a new name; then press the [Rename]
       function key.  The previously configured name is replaced, and the
       screen displays the new name in a display field under the label
       Configured Gateways.

   *   To delete an existing gateway identification, specify the gateway
       name, then press the [Delete] function key.  Press the [Delete]
       function key again to confirm the deletion.  The previously
       configured name is deleted and is no longer displayed in a display
       field under the label Configured Gateways.

Fields

Gateway name          Enter a name to represent a gateway node on this
                      point-to-point network, through which one or more
                      remote networks can be reached.  A gateway name can
                      contain as many as eight alphanumeric characters;
                      the first character must be alphabetic.

New name              (Required only when renaming a gateway.)  Enter a
                      name to represent a gateway node on this
                      point-to-point network.  This new gateway name is
                      used in place of the current gateway name for an
                      existing gateway configuration.  The name can
                      contain as many as eight alphanumeric characters;
                      the first character must be alphabetic.
