HP ALLBASE/BRW Reference Manual

Define HPDesk Configuration Screen

Use this screen to define all the information necessary to allow HP
ALLBASE/BRW to submit a report or output file to HPDesk.




HPDesk distributes the report according to the information entered here.


NOTE  You will only be able to access this screen if you have purchased
      HP BRW-Desk/XL.


Access this screen by choosing Define Delivery on the Define Report
screen or appropriate Output File screen.

To define HPDesk delivery information

   1.  Type a literal address in the Name/Address field, or type the name
       of an item which contains or will calculate the address in the
       contained in Item field.

   2.  Press Enter.

   3.  A copy of the report or output file is sent to every address on
       this screen.

   4.  Choose Next/Prev Values to review more names/ addresses.

To Delete the HPDesk Delivery

   1.  Choose Delete Delivery to select the HPDesk delivery of the report
       or output file.

Field Descriptions

Subject

Optional.  Used by HPDesk as the subject of the message.  You can use a
string constant, a database item, or a calculated item.  (The item type
must be S(tring).

Name/Address Fields

Use these fields to specify the recipients of a message, using the
standard HPDesk conventions for recipient categories.  These fields are
used to describe the complete distribution list for a message.

FROM, TO, CC, BCC

The category of the sender and each recipient.  At least one recipient is
required.  You don't need to specify the sender if you want the message
to use the name of the sender(s) configured in BRWCONF. See Chapter 17
 for information about configuring HP ALLBASE/BRW for HPDesk.

Name/Address

Optional.  Type a string constant in the Name/Address field, or the name
of a database item or calculated item in the contained in Item field (if
you use items, the item type must be S(tring) to specify the name and
address of the recipient(s).  You can use up to 200 names/addresses with
each message; HPDesk will attempt to deliver to all the names.

The string constant or item can specify an HPDesk name/address or a
distribution list.  With distribution lists, the Public Distribution
Lists in the Filing Cabinet are searched first, then the List Area of the
sender is searched.  Names/ addresses must be in the following HPDesk
format.

       [firstname [secondname]]

       surname [/location [/sublocation]]

These HPDesk addresses are not validated by the BRW specification and
compile programs.

Split Report/File and Switch Destination on Break Level

Optional.  The break level where the report or output file will be split
and the destination switched, that is the report or output file will be
divided into portions where each of them will be sent to individual
destinations.  The default is no Destination Switch which means that the
whole report or output file will be sent to the specified destination.

Urgent

Optional.  Use this field to make your message URGENT. If not specified,
a default of NORMAL is taken for a message.

Private

Optional.  Use this field to define the security of the message.  If not
specified the message will be given a security level of NORMAL (that is,
not PRIVATE).

Acknowledgment

Optional.  Use this field to define the level of Acknowledgment required
on the message.  As per standard HPDesk conventions, it will apply to
just the TO recipients.  The default will be that no Acknowledgment will
be requested.

Acknowledgment Level - values:

      0 - No Acknowledgment requested
      1 - Transmitted Acknowledgment requested
      2 - Receipt Acknowledgment requested
      3 - Delivered Acknowledgment requested
      4 - Read Acknowledgment requested
      5 - Reply Acknowledgment requested

Print Report with CCTL/NOCCTL

Optional.  You can send a report via HPDesk with or without carriage
control codes.  Files without carriage-control codes will be larger.  The
default is to send the report to HPDesk with carriage-control codes
(CCTL).

Print Report additionally

Optional.  Can be used only when defining delivery of report files.  Use
this field to specify that a report must be printed.  The default is to
suppress the printing of the report.
[REV BEG]

Mail Time
[REV END]

Optional.  Use this field to specify the time when the message should be
mailed.  The message will remain in the out-tray of the sender with
status:  'deferred' mail until the time specified.  If the specified time
has already passed (for example, mail time 1.00) and you run the report
at 12:00, the message will be deferred until 1:00 the following day.

The default is:  mail the message immediately.

Softkeys

Delete Delivery

Press this key to delete the delivery specification.  At the prompt,
press the key again to confirm the deletion.

Prev/Next Values

Use these keys to add more than 8 recipients to a message.  Up to 200
recipients may be defined for a message.  This number includes all names
specified by FROM, TO, CC, BCC, plus all names appearing in distribution
lists.  This number is the maximum number that is supported by HPDesk and
is not checked by BRW at specification time.
