Lesson 2 Examining a Job File

Introduction

Lesson 2 provides the following information about the structure and use
of a job file:

* job commands and how they are used

* input and output processing and printing priorities

* Modifying a job file.

In this lesson, you will examine a sample job file to see how job files
are organized and what kinds of commands are used within these files.

Figure 3-1. Examining a Job File

Start the editor and list the MYJOB (job) file to your screen. (MYJOB is
in the CLASS group of your account.) This file contains examples of
commands used in this lesson. The editor commands and job listing appear
below.

EDITOR
/T MYJOB1
/L ALL

Job files are generally created by using an editor or a word processor
and may consist of four types of command:

* MPE/iX batch processing commands

* other MPE/iX commands

* user-defined commands (UDC) and command files (module 5)

* application commands (optional)

You will learn about user-defined commands and command files in module 5,
"UDCs and Command Files."

Batch processing commands

These five MPE/iX commands are used almost exclusively in job/batch files
are:

-------------------------------------------------------------------------------------------
| |
| Command Line Number |
| in MYJOB File |
| |
-------------------------------------------------------------------------------------------
| |
| JOB 1 |
| |
| COMMENT 3 |
| |
| CONTINUE 4 |
| |
| TELL 9 |
| |
| EOJ 10 |
| |
-------------------------------------------------------------------------------------------

When MPE/iX commands appear in a job file, they must be preceded by an
exclamation point (!). The ! tells the system that what follows should
be treated as an MPE/iX command.

Each of these commands is described and explained in both the MPE/iX
Commands Reference Manual Volumes 1 and 2 (32650-90003 and 32650-90364)
and the Help facility. Select either resource for more information on
the purpose and parameters of each of the commands as they are explained
in this lesson.

JOB command

!JOB MYJOB1,USERx/UPASSx.ACCTx/APASSx,&
!CLASS;INPRI=9;RESTART;OUTCLASS=LP,1;SPSAVE

NOTE When a JOB command is too long to be written on one physical line
on the screen, it may be continued onto succeeding lines. To show
the continuation, an ampersand (&) is entered at the end of the
each physical line. Each line of the continued command must begin
with an exclamation point (!). A command continued over several
lines with & may consist of as many as 279 characters, including
spaces and ampersands, but not including the ! in the column one
position.

Every job file requires the inclusion of a !JOB command.

The purpose of the JOB command is to initiate a batch job. It is always
the first executable line of any job and contains additional information
regarding the location of the file materials, user and account names, and
so on. (The JOB command is to batch processing what the HELLO command is
to interactive processing.)

By using the required and optional parameters of the JOB command, you
tell the system that the commands that follow should be executed as a
job. Which of the JOB command parameters are required? Which are
optional? Use your reference source and mark this information in the
following table.

Q3-14

Hint HELP JOB

User/account names/passwords

!JOB MYJOB1,USERx/UPASSx.ACCTx/APASSx,CLASS;

Most JOB commands begin with the name of the job followed by the user
name, account name, and logon group name. While not required, including
the name of a job file in a JOB statement can provide for easy
identification of the file.

Unlike sessions, where MPE/iX prompts for passwords, job files must
contain the required user, account, and group passwords to work.
Therefore, the passwords (if any) for the user, account, and group must
follow each of these names. Notice that the passwords must be
joined to the user, account, or group name by a backslash (/):
!JOB...USERx/UPASSx.ACCTx/APASSx....

--------------------------------------------------------------------------------------------
| |
| Q3-15 What are the job name, user name, account name, and group name specified in |
| the JOB command in the MYJOB file? |
| |
| |
| Q3-16 If the password for the CLASS group is LASER, will the job run with the JOB |
| command stated as is? |
| |
| |
--------------------------------------------------------------------------------------------

Input priority

!JOB MYJOB1...;INPRI=9...

Remember the importance of the input priority?

The input priority (INPRI) must be greater than the current jobfence in
order for a job to execute.

What is the input priority for MYJOB?

It is 9. If you were going to run MYJOB now on your system, would it
run? (Use SHOWJOB to check the jobfence on your system to find out.)

RESTART parameter

!JOB MYJOB1,USERx/UPASSx...;RESTART;...

The RESTART parameter ensures that a job will restart in the event of a
system halt and start. A job with this parameter restarts processing
from the beginning; however, no work already done will be undone.

NOTE RECOVERY Option

Your system operator may choose to restart a system with either the
RECOVERY or the NORECOVERY option. RECOVERY is the default option,
and it ensures that all jobs that include the RESTART option will
be restarted. It also ensures the starting of any job that had not
yet started at the time of the system halt.

No jobs of any kind are restarted if the system is brought back up
with the NORECOVERY option.

--------------------------------------------------------------------------------------------
| |
| Q3-17 What happens to your job if your system crashes and you do not have the |
| RESTART parameter in your JOB command? |
| |
| |
--------------------------------------------------------------------------------------------

OUTCLASS parameter

!JOB MYJOB1...;OUTCLASS=LP,1

The OUTCLASS parameter refers to a "job listing," not to the actual
finished result you expect from a job. This parameter lets you set the
following:

* device where the job listing is to be printed.

* job listing's outclass priority.

* number of copies of the job listing to be printed.

Outclass priority values range from 1 (low) to 13 (high). The output
priority value must be set above the system outfence value in order to
enable the job listing to print.

To check on the current outfence value for your system enter:

SHOWOUT

In order for a job listing to print, the outclass priority must be set
above the system's outfence value.

NOTE The job listing is a copy of the step-by-step processing of the
job. Most users suppress the printing of the job listing unless
the job has previously experienced some problems executing. When
problems occur, review the job listing to find where the error(s)
occurred.

SPSAVE parameter

A $STDLIST spool file is generated when you run a job. It is usually
destined for the printer when the job has executed.

Normally, the spool file is automatically erased after it is printed.
The optional ;SPSAVE parameter instructs the system to save the $STDLIST
spool file until you or the system manager explicitly purge it.

Hint: A low output priority may prevent a spool file from printing, and
the spool file will appear to be saved; but the spool file will
disappear after it is allowed to print. The ;SPSAVE option,
however, saves the spool file after printing.

Saving a spool file can be useful for a job that is likely to execute
quickly. By saving the spool file, you ensure yourself the opportunity
of examining it with the PRINT command.

MYJOB is a small job and, if the system is not very busy, will execute
quickly.

--------------------------------------------------------------------------------------------
| |
| Q3-18 Assuming that the system outfence value is set at 6, which !JOB command |
| ensures that the job listing will print? |
| |
| |
| a. !JOBx........INPRI=9;OUTCLASS=LP,5 |
| |
| b. !JOBx........INPRI=9;OUTCLASS=LP,6 |
| |
| c. !JOBx........INPRI=9;OUTCLASS=LP,8 |
| |
| Q3-19 Where will the job listing from MYJOB appear? |
| Given a system outfence value of 4, will the job listing for MYJOB print? |
| |
| |
--------------------------------------------------------------------------------------------

COMMENT command

!COMMENT MYJOB1 PRINTS MYFILE1

The COMMENT command inserts a comment into the command stream. The
purpose of the comment is for the benefit of the user, since no execution
is done. Comments may appear anywhere in a job file.

Including a comment regarding the purpose of a job can be helpful when
you have multiple users of a single job.

CONTINUE command

!CONTINUE

How do you avoid a job aborting when it encounters an error?

The CONTINUE command enables a job to continue to process if it appears
immediately before a command line that may cause an error during a job's
processing; therefore, the job continues to execute even if an error
occurs, and the job listing contains the error message where the error
occurred.

Look at line 4 in MYJOB. Inserting the CONTINUE command on this line
ensures that if the system encounters a problem with line 5, the job will
not abort there.

TELL command and TELLOP command

!TELL USERx.ACCTx MYJOB1 IS DONE!!

The TELL command can be inserted at one or more points in the job to send
reports to the screen indicating your job's progress. The TELLOP command
is used to alert system operators to perform some action regarding the
job such as loading a tape or changing paper on the printer.

--------------------------------------------------------------------------------------------
| |
| Q3-20 What prints on USERx's screen when MYJOB completes processing? |
| |
| |
--------------------------------------------------------------------------------------------

EOJ command

!EOJ

The !EOJ command terminates a job and displays the following
information on the job's printout: CPU time (in seconds), time elapsed
since the beginning of the job, and the date and time.

The !EOJ command is on the last line in a job file.

Other commands in job files

Some jobs may involve the use of a word processor or other kind of
application or utility, for example EDIT/3000 or SORT. Any application
that normally executes from a system prompt can be included in a job file
preceded by an exclamation point:

!EDITOR
!SORT

Notice that after the editor is invoked (!EDITOR), the EDIT/3000 commands
are entered in the job file exactly the way you would enter them if you
were using the editor interactively at your terminal: T MYFILE1 and LIST
ALL, OFFLINE. These commands are internal to the application (the editor)
and must not have the ! ahead of them

--------------------------------------------------------------------------------------------
| |
| Q3-21 What is the purpose of the !EDITOR line in MYJOB? |
| |
| |
| Q3-22 What is the purpose of the T MYFILE1 line in MYJOB? |
| |
| |
--------------------------------------------------------------------------------------------

Exercise 3-2: modifying the MYJOB2 file.

Here's a chance to check your own knowledge about batch processing
commands and their use.

Suppose that you have been given the following jobfile (MYJOB2). This
job lists the contents of a text file titled MYFILE2; however, the job
file needs to be modified in order to run correctly.

Use the editor to access and list MYJOB2 on your screen. (This file
should be in your account.)

EDITOR
/T MYJOB2

1. Modify the JOB command to show your user and account name as well
as your passwords.

2. Verify the current jobfence. Modify the input priority in the JOB
command to a value that enables the job to run.

3. You want to be sure that should the system halt while the job is
processing, the processing restarts when the system is restarted.
Enter that parameter in the JOB command to ensure that this
happens.

4. Suppose that several times in the past a user has encountered some
problems in processing MYFILE2. Therefore, you want to check the
job listing before it is printed.

Verify the current system outfence:

SHOWOUT

Modify the OUTCLASS parameter to a value that ensures that the job
listing will not print.

5. MYFILE2 is now located in the CLASS group in your account. Modify
the appropriate lines in the job file to reflect MYFILE2's correct
location.

6. Add a line in the job file to provide a screen message noting that
your job has completed processing.

7. Check over the file once again to ensure that all JOB commands are
preceded by an exclamation point (!).

8. Check your modifications against those in the Solutions Guide.
Then process MYJOB2 by entering

STREAM MYJOB2

If all the changes were made correctly, you should soon see a
message similar to this:
________________________________________________________________________
| |
| FROM/Jxx USERx.ACCTx MYJOB2 IS COMPLETE |
| |
________________________________________________________________________

Two sorts of errors can occur the jobs you have been working with.

a. The STREAM command detects a significant error in the job
file itself--a missing or invalid !JOB command; a missing
or invalid password; account or groupname; a missing or
invalid device specification.

Such errors will be reported on your screen. If the error
is serious, the stream or the job execution may fail.

b. In the jobs that you have used so far, the editor detects
an error--an invalid file name; an editor command to change
something not found in your text.

Such errors will turn up in your job listing.

That is why it is a good idea to specify ;SPSAVE in your !JOB
command line. That way, you can use the PRINT command to examine
your spool file to see what error the editor encountered. (In a
later section, you will learn how to use LISTSPF and the PRINT
command to check for errors.)

********** End of Exercise 3-2 **********

Lesson summary

1. The JOB command initiates a batch job and contains required
information regarding the location of the relevant files, user and
account names, and processing priority.

2. A job must have an input priority higher than the current jobfence
in order to begin processing.

3. The job listing prints only if the job's output priority is above
the outfence priority.

4. The CONTINUE command ensures that a job will continue to process
if it appears before a command line that may cause an error during
the job's processing.

5. The RESTART parameter ensures that an executing job will restart
in the event of a system halt and system start, provided that the
system is restarted with the RECOVERY option.

MPE/iX 5.0 Documentation
